Flomatic Valves Model Cycle
The Model Cycle Gard IV CB152SST from Flomatic Valves is a stainless steel, direct-acting, constant-pressure pump control valve with tappings. The body is equipped with 1-inch NPT-size female inlet threads and 1-inch NPT union end female outlet connection. The valve’s standard pressure range is 15 to 75 psi with an optional 15 to 150 psi range. The valve body maximum pressure rating is 400 psi. All of the valve’s internal parts are corrosion resistant with a stainless steel spring and fasteners for long service life. It maintains a preset operating pressure, reduces rapid pump cycling and is proven
