A new approach studied by the Department of Energy's Pacific Northwest National Laboratory eliminates the need to dry biosolids before refining.
Wastewater treatment plants across the country may one day turn sewage into biocrude oil, thanks to new research from the Department of Energy's Pacific Northwest National Laboratory.
The technology — hydrothermal liquefaction — mimics the geological conditions the Earth uses to create crude oil, using high pressure and temperature to achieve in minutes something that takes Mother Nature millions of years.
The resulting material is similar to petroleum pumped out of the ground, with a small amount of water and oxygen mixed in. This biocrude then can be refined using conventional petroleum refining operations.
Wastewater treatment plants across the U.S. treat approximately 34 billion gallons of sewage every day — an amount that could produce up to 30 million barrels of oil per year. PNNL estimates that a single person could generate two to three gallons of biocrude per year.
Biosolids have been viewed in the past as a poor ingredient for producing biofuel because they’re too wet. The approach being studied by PNNL eliminates the need for drying required in a majority of current thermal technologies which historically has made wastewater to fuel conversion too energy intensive and expensive.
Hydrothermal liquefaction also may be used to make fuel from other types of wet organic feedstock, such as agricultural waste.
Using hydrothermal liquefaction, organic matter such as human waste can be broken down to simpler chemical compounds. The material is pressurized to 3,000 pounds per square inch — nearly one hundred times that of a car tire.
Pressurized biosolids then go into a reactor system operating at about 660 degrees Fahrenheit. The heat and pressure cause the cells of the waste material to break down into different fractions — biocrude and an aqueous liquid phase.
"There is plenty of carbon in municipal waste water sludge and interestingly, there are also fats," says Corinne Drennan, who is responsible for bioenergy technologies research at PNNL. "The fats or lipids appear to facilitate the conversion of other materials in the wastewater such as toilet paper, keep the sludge moving through the reactor and produce a very high quality biocrude that, when refined, yields fuels such as gasoline, diesel and jet fuels."
In addition to producing useful fuel, hydrothermal liquefaction could give local governments significant cost savings by virtually eliminating the need for sewage residuals processing, transport and disposal.
"The best thing about this process is how simple it is," says Drennan. "The reactor is literally a hot, pressurized tube. We've really accelerated hydrothermal conversion technology over the last six years to create a continuous and scalable process which allows the use of wet wastes like sewage sludge."
An independent assessment for the Water Environment & Reuse Foundation calls hydrothermal liquefaction a highly disruptive technology that has potential for treating wastewater solids. WE&RF investigators note that the process has high carbon conversion efficiency with nearly 60 percent of available carbon in primary sludge becoming biocrude. The report calls for further demonstration, which may soon be in the works.
PNNL has licensed its hydrothermal liquefaction technology to Utah-based Genifuel Corporation, which is now working with Metro Vancouver — a partnership of 23 local authorities in British Columbia, Canada — to build a demonstration plant.
"Metro Vancouver hopes to be the first wastewater treatment utility in North America to host hydrothermal liquefaction at one of its treatment plants," says Darrell Mussatto, chair of Metro Vancouver's Utilities Committee. "The pilot project will cost between $8 to $9 million (Canadian) with Metro Vancouver providing nearly one-half of the cost directly and the remaining balance subject to external funding."
Once funding is in place, Metro Vancouver plans to move to the design phase in 2017, followed by equipment fabrication, with start-up slated for 2018.
"If this emerging technology is a success, a future production facility could lead the way for Metro Vancouver's wastewater operation to meet its sustainability objectives of zero net energy, zero odors and zero residuals," says Mussatto.
In addition to the biocrude, the liquid phase can be treated with a catalyst to create other fuels and chemical products, according to PNNL. A small amount of solid material is also generated, which contains important nutrients. For example, early efforts have demonstrated the ability to recover phosphorus, which can replace phosphorus ore used in fertilizer production.
The Water Environment & Reuse Foundation (WE&RF) is a 501(c)(3) charitable corporation seeking to identify, support and disseminate research that enhances the quality and reliability of water for natural systems and communities with an integrated approach to resource recovery and reuse. It also facilitates interaction among practitioners, educators, researchers, decision makers and the public.
Metro Vancouver is a partnership of 21 municipalities, one electoral area and one Treaty First Nation that collaboratively plans for and delivers regional-scale services. Its core services are drinking water, wastewater treatment and solid waste management. Metro Vancouver also regulates air quality, plans for urban growth, manages a regional parks system and provides affordable housing. The regional district is governed by a Board of Directors from each local authority.
